Sales Service Provided Color Sorting machinery For Processing Wheat
Grain Color Sorter Machine Description
Its working principle is to divide materials into different groups according to different colors, so as to improve the quality of materials. For example, it can classify moldy nuts, separate red plastic particles from mixed color groups, remove bad rice, etc.
When the color sorter is working, the feeding hopper will evenly distribute the materials in each chute under the action of the vibrator, and then the camera will scan and calculate the fallen materials. If the unqualified materials or impurities are found in the materials, the ejector will blow the defective products into the hopper.
Technical advantages
| Intelligent Dimming light source | Non-polar dimming, Shadow-less lighting, Matching the Optimum illumination brightness According to Marital Characteristic. |
| High Quality 5K Camera | Ultra Clear Image, Minimum recognition accuracy 0.04 mm, making tiny defect be invisible. |
| SMC Imported Ejector From Japan | High quality, high frequency and long life; saving air consumption, electricity and energy. |
| SMC Air Filter System From Japan | Extraordinary Performance Due to “Tone” Fresh. |
| Multidimensional Stereo Specialized Algorithms | Unique Recognition Algorithms for Color, Shape, Texture and Angle, Comprehensive, multidimensional, Due to Professional So Powerful. |
| High Quality Image Processing System | New Generation of ARM+FPGA Processor Technology, Arithmetic Speed will be much faster. |
| Easy Operation Screen | Easy Machine Operate , You will be also sorting expert. |
| Fully Covered Dust Cleaning and Vacuum Cleaning System | Smoothly dust cleaning, strongly dust absorption, fully coverage, none dead angle, easy to handle with high dust environment. |
Technical Parameters
| Model | Throughput(t/h) | Channel
number | Sorting
Accuracy(%) | Power
(kw) | Power Supply | Demension L*W*H(mm) | Weight
(kg) |
| Glory-1 | 0.5 ~ 0.9 | 64 | >99 | 1.0 | 110-220V/50HZ-60HZ | 1465*1764*2341 | 365 |
| Glory-4 | 3 ~ 6 | 256 | >99.99% | 2.4 | 110-220V/50HZ-60HZ | 2232*1764*2341 | 955 |
| Glory-5 | 4 ~ 8 | 320 | >99.99% | 3.0 | 110-220V/50HZ-60HZ | 2546*1764*2341 | 1120 |
| Glory-6 | 5 ~ 8 | 384 | >99.99% | 3.6 | 110-220V/50HZ-60HZ | 2860*1764*2341 | 1285 |
| Glory-7 | 5 ~ 10 | 448 | >99.99% | 4.1 | 110-220V/50HZ-60HZ | 3174*1764*2341 | 1460 |
| Glory-8 | 8 ~ 12 | 512 | >99.99% | 4.7 | 110-220V/50HZ-60HZ | 3488*2764*2341 | 1640 |
| Glory-10 | 10 ~ 16 | 640 | >99.99% | 5.4 | 110-220V/50HZ-60HZ | 4116*1764*2341 | 2000 |
Sorting examples
| Color Sorter Applications |
| Beans | kidney bean/soybean/mung/red bean/black bean/pea/ broad bean/coffee bean/lentil/chickpea |
| Tea | green tea/black tea/dark tea/white tea/ yellow tea |
| Cereals | corn/barley/wheat/oat/sesame/malt |
| Seeds | cotton seed/corn seed/wheat seed/pepper seed/onion seed |
| Nuts & Kernels | sunflower seed/pumpkin seed/watermelon seed/cashew nut/peanut/walnut/pistachio |
| Industrial Goods | quartz sand/recycled plastic/salt/mineral/monosodium glutamate/white sugar/pill/pearl |
| Economic Crops | raisin/medlar/lily/red date/shrimp bran/tobacco/agaric |
After Sales Services
Free software upgrade services for our customers lifelong.
One year warranty and free maintenance.
Engineers available to service machinery overseas.
Packaging & Shipping
Inner packing is vaccuum-packed with aluminum foil.
External packing is fumigation-free wood packages.
Suit for long sea voyage.
Our Services :
We adhere to the principle of Customer priority, encourage employees to care about customer demand, and provide solutions for both domestic and overseas customer.
We provide customer with one year free repair and maintenance for complete machine, and prompt professional training and technical guidance, which fully embodies our service mode featuring fast response, timely maintenance and follow-up coordination.
Service commitment: One year free repair and maintenance for complete machine, 7x24h consultation service .No matter where you are, you can visit us .
